Feature
-Fan motor over load Protection
-Automatic reset function incoming power cut
-Buzzer on and UV Lamp cut off when set time arrived
-UV Lamp turns off as window opens
-Emergency stop button
Option
-Air&Gas Port
Specifications
| Model | SH-HD-900V |
| Type | Laminar Vertical Down Flow |
| Dimension Internal (WxDxH) | 860×613×690(mm) 33.86x24.13x27.17(inch) |
| Dimension External (WxDxH) Control System | 966×696×1820(mm) 35.43x30.71x74.80(inch) Microprocessor LCD Digital Controller |
| Main Filter | Hepa Filter 0.3μ 99.97% Efficiency Filter |
| Material External | Steel Plate with Power Heating Coated |
| Working Table | Stainless Steel |
| Illumination UV Lamp | 15W×1EA |
| UV Time Range | 00.00 to 99HR 59 MIN (MIN SEC) Selectable LCD Counter |
| Winding Velocity | 0.2~2.3M/SEC, 10 Step Adjustable |
| Purity | Below to Class 100 |
| Door Type | Tempered Glass by Weight Balance |
| Illumination FL Lamp | 15W×1EA |
| Electrical Requirements | 120V,230V, 1Φ |
| Weight | 130 Kg |
